Dell N4032F 24-Port 10GB SFP+ Ports L3 Layer 3 Managed Stackable Network Switch PowerConnect 8132F

$699.99

Switch Grade A, in Great condition Read Description.

Out of stock

This Dell N4032F Managed Layer 3 10xGigabit Network Switch is guaranteed to be in good working and physical condition with minor scratches and scuffing from normal use.

Switch : Grade A.

It was tested with the following notes from our testing technician:

  • It was powered on and pass the self test with no problems.
  • All ports led during the self test with no problems.
  • all the fans are functional.
  • Front LED Display Work Great.
  • A serial connection was established with the switch with no issues.(check photos)
  • after the test the switch was restored to its factory default, previous configuration erased.
  • two power supplies is provided for redundancy tested with no issues.
  • Stacking module front slot cover is missing. (see Photos)

Features & Specs:

  • Ports: 24x 10GbE SFP+ auto-sensing (10Gb/1Gb) fixed ports, 1x hot swap expansion module bay.
  • PSU: 2x redundant 460W PSU
  • Stack-able: yes
  • Management- & Configuration-Port Attributes: 1 RJ45 console/management port with RS232 signaling, 1 Out-of-Band (OOB) Management Port (10/100/1000BASE-T),1 USB (Type A) port for configuration
  • Switch Fabric Capacity (full duplex): 640Gbps
  • Forwarding Rate: 476Mpps
  • stacking speed (full-duplex): 160Gbps
  • CPU: 1200MHz
  • Memory: 2GB
  • Flash Memory: 256MB
  • Weight : 21.67 lbs
  • Dimension: 1.71 x 17.08 x 18.11

Because we have a quantity of these, the photos are representative of the item you will receive. Your item will be in the same or better condition as the one shown in the photos.

Note: These item is consigned for sale by a local county.

Serials: Serials: CN0PDJ932829848K0164A02

Includes:

  • 1x Dell N4032F 24-Port 10GB SFP+ Ports L3 Layer 3 Managed Stackable Network Switch  PowerConnect 8132F
  • 2x Power Supply 460 watt  (Attached)
  • 1x Fan Module
  • 1x Slide rails Type A5 P/N: JKTTN
  • 1x Standard Power Cable

Does Not Include:

  • User Guide
  • Serial Cable / Ethernet or stacking Cables / Transceiver.
  • Anything else not listed or pictured above
Weight 22 lbs
Dimensions 24 × 22 × 6 in
Manufacturer Part Number

PowerConnect 8132F N4032F

Color

Black

Product Type

10GbE Switch

Others

Ports: 24x 10GbE SFP+ auto-sensing (10Gb/1Gb) fixed ports, 1x hot swap expansion module bay.
PSU: 2x redundant 460W PSU
Stack-able: yes
Management- & Configuration-Port Attributes: 1 RJ45 console/management port with RS232 signaling, 1 Out-of-Band (OOB) Management Port (10/100/1000BASE-T),1 USB (Type A) port for configuration
Switch Fabric Capacity (full duplex): 640Gbps
Forwarding Rate: 476Mpps
stacking speed (full-duplex): 160Gbps
CPU: 1200MHz
Memory: 2GB
Flash Memory: 256MB
Weight : 21.67 lbs
Dimension: 1.71 x 17.08 x 18.11

Condition Used
Notes Switch Grade A, in Great condition Read Description.
